AMC CHINA HK LIMITED

Network Communication	Environment	Form Factor	DC Supply Voltage (VDC)	Current Continuous (A)	Current Peak (A)	Part Number
EtherCAT	Standard	Development Board	10-55	10	20	FD060-10-EM
			10-55	25	50	FD060-25-EM
			10-55	5	10	FD060-5-EM
			10-55	60	60	FD060-60C-EM
			18-90	25	50	FD100-25-EM
			20-90	50	100	FD100-50-EM
		PCB Mount	10-55	10	20	FE060-10-EM
			10-55	1	2	FE060-1-EM
			10-55	25	50	FE060-25-EM
			10-55	5	10	FE060-5-EM
			10-55	60	60	FE060-60C-EM
			18-90	25	50	FE100-25-EM
			20-90	50	100	FE100-50-EM
		Machine Embedded	10-55	10	20	FM060-10-EM
			10-55	1	2	FM060-1-EM
			10-55	25	50	FM060-25-EM
			10-55	5	10	FM060-5-EM
			10-55	60	60	FM060-60C-EM
			18-90	25	50	FM100-25-EM
			20-90	50	100	FM100-50-EM
		Panel Mount	10-55	25	50	FMP060-25-EM
	Extended	PCB Mount	10-55	10	20	FXE060-10-EM
			10-55	25	50	FXE060-25-EM
			10-55	5	10	FXE060-5-EM
		Machine Embedded	10-55	10	20	FXM060-10-EM
			10-55	25	50	FXM060-25-EM
			10-55	5	10	FXM060-5-EM

CANopen	Standard	Development Board	10-55	10	20	FD060-10-CM
			10-55	25	50	FD060-25-CM
			10-55	5	10	FD060-5-CM
			10-55	60	60	FD060-60C-CM
			18-90	25	50	FD100-25-CM
			20-90	50	100	FD100-50-CM
		PCB Mount	10-55	100	200	FE060-100-CM
			10-55	10	20	FE060-10-CM
			10-55	1	2	FE060-1-CM
			10-55	25	50	FE060-25-CM
			10-55	5	10	FE060-5-CM
			10-55	60	60	FE060-60C-CM
			18-90	25	50	FE100-25-CM
			20-90	50	100	FE100-50-CM
		Machine Embedded	10-55	100	200	FM060-100-CM
			10-55	10	20	FM060-10-CM
			10-55	1	2	FM060-1-CM
			10-55	25	50	FM060-25-CM
			10-55	5	10	FM060-5-CM
			10-55	60	60	FM060-60C-CM
			18-90	25	50	FM100-25-CM
			20-90	50	100	FM100-50-CM
	Extended	PCB Mount	10-55	10	20	FXE060-10-CM
			10-55	25	50	FXE060-25-CM
			10-55	5	10	FXE060-5-CM
		Machine Embedded	10-55	10	20	FXM060-10-CM
			10-55	25	50	FXM060-25-CM
			10-55	5	10	FXM060-5-CM

RS485/232	Standard	Development Board	10-55	10	20	FD060-10-RM
			10-55	25	50	FD060-25-RM
			10-55	5	10	FD060-5-RM
			10-55	60	60	FD060-60C-RM
			18-90	25	50	FD100-25-RM
			20-90	50	100	FD100-50-RM
		PCB Mount	10-55	10	20	FE060-10-RM
			10-55	1	2	FE060-1-RM
			10-55	25	50	FE060-25-RM
			10-55	5	10	FE060-5-RM
			10-55	60	60	FE060-60C-RM
			18-90	25	50	FE100-25-RM
			20-90	50	100	FE100-50-RM
		Machine Embedded	10-55	10	20	FM060-10-RM
			10-55	25	50	FM060-25-RM
			10-55	5	10	FM060-5-RM
			10-55	60	60	FM060-60C-RM
			10-55	1	2	FM060-1-RM
	Extended	PCB Mount	10-55	10	20	FXE060-10-RM
			10-55	25	50	FXE060-25-RM
			10-55	5	10	FXE060-5-RM
		Machine Embedded	10-55	10	20	FXM060-10-RM
			10-55	25	50	FXM060-25-RM
			10-55	5	10	FXM060-5-RM

Ethernet/IP	Standard	Development Board	20-90	50	100	FD100-50-IPM
		PCB Mount	10-55	10	20	FE060-10-IPM
			10-55	25	50	FE060-25-IPM
			10-55	5	10	FE060-5-IPM
			20-90	50	100	FE100-50-IPM
		Panel Mount	10-55	25	50	FMP060-25-IPM

Network Communication	Environment	Form Factor	DC Supply Voltage(VDC)	Current Continuous(A)	Current Peak(A)	Part Number
EtherCAT	Standard	Panel Mount	10-55	1	2	CFD060-1-EM
			10-55	5	10	CFD060-5-EM
			10-55	10	20	CFD060-10-EM
			10-55	25	50	CFD060-25-EM
	Extended		10-55	5	10	CFXD060-5-EM
			10-55	10	20	CFXD060-10-EM
			10-55	25	50	CFXD060-25-EM
CANopen	Standard		10-55	1	2	CFD060-1-CM
			10-55	5	10	CFD060-5-CM
			10-55	10	20	CFD060-10-CM
			10-55	25	50	CFD060-25-CM
	Extended		10-55	5	10	CFXD060-5-CM
			10-55	10	20	CFXD060-10-CM
			10-55	25	50	CFXD060-25-CM
